| Parameter | Symbol | Min | Type | Max | Unit | Test Condition |
| Threshold Current | Ith | 0.4 | - | 3 | mA | - |
| Forward Voltage | Vop | - | 1.9 | 2.2 | V | - |
| Optical Output Power | Pout | 0.4 | - | - | mW | Iop = 9mA |
| Center Wavelength | λc | 840 | 850 | 860 | nm | |
| Rise/Fall Time | Tr/Tf | - | 0.11 | 0.3 | ns | 20-80% |
| Slope Efficiency | SEh | 0.05 | - | - | mW/mA | Iop = 9mA |
| Monitor Current (PD) | Im | 10 | - | 400 | uA | Iop = 9mA |
| Dark Current (PD) | Id | - | - | 100 | nA | VR=10V |
| Capacitance (PD) | Ct | - | 5 | - | pF | VR =5V,f=1MHz |
