| Parameter | Symbol | Min. | Type | Max. | Unit | Test Condition | |
| 参数 | 符号 | 最小值 | 典型值 | ******值 | 单位 | 测试条件 | |
| Threshold Current | Ith | 4 | -- | 15 | mA | T=25 °C | |
| 阈值电流 | |||||||
| Forward Voltage | Vop | - | 1.2 | 1.7 | V | CW,If=Iop | |
| 正向电压 | |||||||
| Optical Output Power | Pf | 1 | - | - | mW | CW,If=Ith+20mA | |
| 出纤功率 | |||||||
| Center | FP | λc | λ-20 | λ | λ+20 | nm | |
| Wavelength | DFB | λ-10 | λ | λ+10 | |||
| 中心波长 | CWDM | λ-3 | λ | λ+3 | |||
| Rise/Fall Time（10～90）% | Tr/Tf | - | - | 0.2 | nS | If=Ith,Po=Pf | |
| 上升/下降时间（10～90）% | (10-90)% | ||||||
| Spectral Width ((-20 dB) | Δλ | -- | 1 | 2 | nm | CW, If=Ith+20mA | |
| 光谱 | |||||||
| Monitor Current | Im | 100 | 1000 | uA | CW,P0 = Pf | ||
| 监视电流 | |||||||
| PD Capacitance | CPD | - | 10 | 15 | PF | VRD=5V | |
| PD结电容 | |||||||
| PD Dark Current | Id | - | - | 1 | nA | VRD=5V | |
| PD暗电流 | |||||||
| Side Mode Suppression | SMSR | 35 | 40 | - | dB | CW,Po=2mW | |
| Ration边模抑制比 | |||||||
| Optical Isolation | Iso | 30 | - | - | dB | ||
| 隔离度 | |||||||
