Parameter | Symbol | Min | Type | Max | Unit | Test Condition |
Center Wavelength * | λc | λ-3 | λ | λ+3 | nm | CW |
Threshold Current | Ith | - | 5 | 10 | mA | CW,T=25℃ |
- | 25 | 40 | mA | CW,T=85℃ | ||
Slople Efficiency | η | 0.3 | - | - | W/A | |
Operating Voltage | Vf | - | 1.1 | 1.6 | V | |
Rise/Fall Time | Tr/Tf | - | 50 | - | pS | If, 20% to 80% |
Monitor Current | Im | 0.1 | - | 1 | mA | CW, If=Ith+20mA |
Capacitance | C | - | 10 | 20 | PF | VRD=5V, F=1MHz |
Spectral Width(-20dB) | △λ | - | 0.1 | 1 | nm | CW,If=Ith+20mA |
Side Mode Suppression Ration | SMSR | 35 | - | - | dB | CW |
Wavelength Temperature Coeffcient | △λ/△T | - | 0.08 | 0.1 | nm/℃ | |
Thermoelectric(TEC) | Qmax | - | - | 0.6 | W | |
Imax | - | - | 0.9 | A | ||
Vmax | - | - | 1.2 | V | ||
ΔT | 40 | - | - | K | ||
Thermistor Resistance | Rth | - | 10 | - | kΩ | T=25℃ |
B constant of Rth | B | 3800 | 3930 | 4000 | K | |
Thermistor Current | 10 | 200 | uA | T=25℃ |
